HiQSDR as VNA

Posted on by

Since today the HiQSDR or the original N2ADR frontend might be used as a vector network analyzer for the shortwave range.
Jim wrote a simple tool that displays amplitude and phase between TX port and RX port and can handle some calibration.
Currently it is quite simple and i do not have provisions to measure reflections yet, so i can just measure S21 at the moment.
But for the future it will be a nice feature to have the antenna analyzer built into the transceiver itself.
The picture below shows a simple ugly-style lowpass filter.

HiQSDR as VNA

HiQSDR as VNA

3m EME mesh dish by DG0CN

Posted on by

Gert, DG0CN has send me a picture of the new 3m mesh dish design for EME usage he recently made.
It can be splitted into 6 parts for easy transport. Pretty giant antenna ;)

EDIT 2017/06/28: i got the information that Gert passed away weeks ago. His business will most probably not be continued. The webpage already has gone. RIP.

DRM TX with HiQSDR frontend

Posted on by

Yesterday i used my HiQSDR frontend for transmitting a shortwave radio signal in digital DRM standard.
I had to use the FPGA firmware version 1.2 which contains enhanced filters that allow modulation of signals with a bandwidth of up to 22kHz in IQ mode (+-11kHz around the tuning frequency).
Stefan, DL2STG, did a great job creating support for the HiQSDR within the Gnuradio project. After noticing a IQ swap the 64QAM DRM signal was decodable. See the constellation diagram below.

HiQSDR DRM TX constellation diagram

HiQSDR DRM TX constellation diagram 64QAM
